12E997 General Purpose Chip-Free Thread-Forming Taps

$16.16

Bulk orders will be discounted, please contact us.

The TiCN coating on these taps protects them from wear and is harder and more wear-resistant than a TiN coating.

Product Number: 12E997

Mfr Model	19542
Thread Size	1/4"-20
Tap Material	High Speed Steel
Tap Finish	Bright (Uncoated)
Thread Length	5/8 in
Overall Length	2-1/2 in
Thread Limit	H4
Number of Flutes	4
Primary Material Application	Steel
Thread Direction	Right Hand
Coolant Fed	Non-Coolant Through
Extended Neck	No
Material Grade Machining	5502TC
Measurement System	Decimal Inch
Primary Material Application ISO Code	P
Shank Dia	1/4 in
Shank Length	1-1/2 in
Square Size	0.1910 in
Standards	ANSI
Tap Chamfer	Bottoming
Tap Style	Thread Forming
Threads per Inch	20
UNSPSC	23153305
Country of Origin	USA (subject to change)
Thread Standard	Metric
Features	Blind Holes; Bottoming Entry Taper; Forming Taps
Secondary Material Application	Aluminum; Brass; Bronze; Cast Iron; Copper; Stainless Steel
Secondary Material Application ISO Code	K; M; N
Spiral Direction	Neutral
Class of Fit	2B
Thread Pitch	0.50mm
