16E428 Miniature General Purpose Carbide Corner-Radius End Mills

$21.21

Bulk orders will be discounted, please contact us.

The AlTiN coating on these end mills protects them from wear and is more resistant to high heat than TiN, TiCN, and TiAlN coatings. AlTiN-coated end mills are used for milling hard and abrasive materials. Roughing/finishing end mills remove large amounts of material and create a smooth finish on the workpiece at the same time. Miniature end mills have a small diameter and provide high precision and control over material removal during detailed milling applications.

Product Number: 16E428

SEND INQUIRY

  • Description
Mfr Model AECM-0101-4X
Material Machining Carbide
Finish Machining AlTiN
Measurement System Metric
Milling Dia 1.00 mm
Length of Cut 4.00 mm
Overall Length 50.00 mm
Shank Dia 4.00 mm
Shank Type Machining Straight
End Mill Style Corner Radius
Number of Flutes 4
End Mill Application Roughing/Finishing
Drilling Tool Configuration Individual
End Mill Cutting Type Center Cutting
List Number AECM
Material Grade Machining C2 Micrograin
Primary Material Application Stainless Steel; Steel; Tool and Die Steel
Primary Material Application ISO Code M; P
UNSPSC 23172005
Country of Origin USA (subject to change)
Corner Radius 0.10mm
Helix Angle 30°
Cutting Direction Right Hand
Neck Length 13.5mm
Neck Dia 1.450mm
