2MYG1 General Purpose Finishing Coated Carbide Square End Mills

$169.21

Bulk orders will be discounted, please contact us.

These end mills come in standard sizes expressed in fractional inches. Two-flute end mills help maximize chip clearance. The TiAlN coating on these end mills withstands high temperatures and protects them from wear. It allows the end mills to be used at faster speeds than end mills with a bright finish, and it resists cracks and oxidation better than TiN or TiCN coatings.

Product Number: 2MYG1

SEND INQUIRY

  • Description
Mfr Model 402-875011
Length of Cut 1-1/2 in
Overall Length 4 in
Neck Length 55.00 mm
Measurement System Fractional Inch
Number of Flutes 2
End Mill Style Square
Primary Material Application Aluminum; Cast Iron; Hardened Steel; Steel; Tool and Die Steel
End Mill Cutting Type Center Cutting
List Number 402
Helix Angle 30 °
Cutting Direction Right Hand
Coolant Fed Non-Coolant Through
Drilling Tool Configuration Individual
UNSPSC 23172005
Country of Origin USA (subject to change)
Shank Type Straight
Material Carbide
Finish TiAlN
Milling Diameter 7/8 in
Shank Diameter 7/8 in
End Mill Application Finishing
Material Grade General Purpose
Primary Material Application ISO Code H; K; N; P
Spiral Direction Right Hand
Secondary Material Application Cast Iron; Heat-Resistant Alloy; Stainless Steel
Secondary Material Application ISO Code K; M; S
Material Applications Cast Iron; Stainless Steel; Steel; Super Alloy
Flute Type Helical
Min Helix Angle 40 °
Max Helix Angle 42 °
Neck Dia 15.00 mm
For Material Hardness 48 HRC
