2TNH3 High-Performance Spiral-Point Taps for Nickel & Titanium

$41.39

Bulk orders will be discounted, please contact us.

These taps are designed for tapping nickel and titanium. They have a TiCN coating that protects them from wear and is harder and more wear-resistant than a TiN coating.

Product Number: 2TNH3

Add to Wishlist Add to Compare

SEND INQUIRY

  • Description
Mfr Model 1105612708
Thread Size 7/16"-20
Tap Material VC-10
Tap Finish TiCN
Thread Length 13/16 in
Overall Length 3-1/8 in
Thread Limit H3
Number of Flutes 3
Primary Material Application Nickel; Titanium
Thread Direction Right Hand
Coolant Fed Non-Coolant Through
Drill Bit Size 0.3855 in; 0.3888 in; 0.3920 in; 0.3953 in; 0.3985 in
Extended Neck Yes
Measurement System Fractional Inch
Primary Material Application ISO Code S
Shank Dia 5/32 in
Shank Length 1-27/32 in
Square Size 0.2420 in
Standards ANSI
Tap Chamfer Plug
Tap Thread Size 7/16"-20
Threads per Inch 20
UNSPSC 23153305
Country of Origin Mexico (subject to change)
Thread Standard UNF
Shank Type Machining Straight
Secondary Material Application Hardened Steel; Stainless Steel; Steel
Secondary Material Application ISO Code H; M; P
Spiral Direction Neutral
Class of Fit 6H
