33YY91 Carbide Straight-Flute Machine Taps

$115.60

Bulk orders will be discounted, please contact us.

The bright finish on these taps provides a smooth, polished surface. Non-coolant-through taps do not have coolant holes, so a separate hose is required to bring coolant to the cutting area if it is needed.

Product Number: 33YY91

Add to Wishlist Add to Compare

SEND INQUIRY

  • Description
Mfr Model 22804
Thread Size M2x0.4
Tap Material High Speed Steel
Tap Finish Bright (Uncoated)
Thread Length 11.00 mm
Overall Length 40.00 mm
Thread Limit OH3
Number of Flutes 3
Tap Length Standard JIS
Tap Shank Standard JIS
Primary Material Application Aluminum; Brass; Bronze; Cast Iron; Copper
Thread Direction Right Hand
Coolant Fed Non-Coolant Through
Extended Neck Yes
Measurement System Metric
Primary Material Application ISO Code K; N
Shank Dia 2.99 mm
Shank Length 24.00 mm
Square Size 2.48 mm
Tap Chamfer Bottoming
Tap Style Straight Flute (Hand)
UNSPSC 23153305
Country of Origin Japan (subject to change)
Thread Standard Metric Coarse
Shank Type Machining Straight
Secondary Material Application Composite
Secondary Material Application ISO Code O
Spiral Direction Neutral
Thread Pitch 0.40mm
