35CD08 Miniature CBN Ball End Mills

$318.41

Bulk orders will be discounted, please contact us.

Roughing/finishing end mills remove large amounts of material and create a smooth finish on the workpiece at the same time. The bright finish on these end mills provides a smooth, polished surface. High-performance end mills are designed to last longer and create a finer finish when used in their recommended, first-choice materials than general purpose end mills. They are used in production milling.

Product Number: 35CD08

Add to Wishlist Add to Compare

SEND INQUIRY

  • Description
Mfr Model 8525854
Milling Dia 1 mm
Length of Cut 0.6 mm
Overall Length 50 mm
Shank Dia 6 mm
Neck Length 4.00 mm
Measurement System Metric
Number of Flutes 2
End Mill Style Ball Nose
Primary Material Application Hardened Steel
Material Machining CBN
Finish Machining Bright (Uncoated)
End Mill Cutting Type Center Cutting
List Number 9192
Helix Angle 30 °
Material Grade Machining General Purpose
Cutting Direction Right Hand
Miniature End Mill Yes
Chip Breaker No
Coolant Fed Non-Coolant Through
Drilling Tool Configuration Individual
Shank Type Machining Straight
UNSPSC 23172005
Country of Origin Japan (subject to change)
