1N720
$27.53
$0.00
Mfr Model | C21960 |
Measurement System | Decimal Inch |
Drill Bit Size | 21.50 mm |
Decimal Equivalent | 0.8465 in |
Maximum Drilling Depth | 155.57 mm |
Overall Length | 273.05 mm |
Shank Type Machining | Taper |
Finish Machining | Steam Oxide |
Material Machining | High Speed Steel |
Primary Material Application | Alloy Steel; Carbon Steel; Gray Cast Iron; Low Carbon Steel; Nodular Cast Iron |
UNSPSC | 27112801 |
Country of Origin | China (subject to change) |
Cutting Direction | Right Hand |
Flute Length | 155.57 mm |
Flute Type | Spiral |
Standards | ASME B94.11M |
Drill Bit Point Angle | 118 ° |
Drill Bit Point Type | Radial Point |
Number of Flutes | 2 |
Spiral Direction | Right Hand |
Helix Angle | 21° to 34° |
Depth Dia Ratio | 4xD |
Primary Material Application ISO Code | K; P |
Material Grade Machining | General Purpose |
Coolant Fed | Non-Coolant Through |
Drill Diameter Tolerance | +0.0000 in/-0.0012 in |
